The ceramic filter works based on the action principle of capillary and micropore, uses microporous ceramics as the filter medium, uses a large number of narrow microporous ceramics, and the solid-liquid separation equipment designed based on the capillary action principle. The disc filter in the negative pressure working state uses the unique water and air tight characteristics of microporous ceramic filter plate to extract the vacuum in the inner cavity of ceramic filter plate and generate the pressure difference with the outside, The suspended materials in the chute are adsorbed on the ceramic filter plate under the action of negative pressure. The solid materials cannot be intercepted on the surface of the ceramic plate through the microporous ceramic filter plate, while the liquid can smoothly enter the gas-liquid distribution device (vacuum barrel) for external discharge or recycling due to the effect of vacuum pressure difference and the hydrophilicity of the ceramic filter plate, so as to achieve the purpose of solid-liquid separation.
The shape and mechanism of the ceramic filter are similar to the working principle of the disc vacuum filter, that is, under the action of pressure difference, when the suspension passes through the filter medium, the particles are intercepted on the surface of the medium to form a filter cake, and the liquid flows out through the filter medium to achieve the purpose of solid-liquid separation. The difference is that the filter medium ceramic filter plate has micropores that produce capillary effect, so that the capillary force in the micropores is greater than the force exerted by vacuum, so that the micropores are always filled with liquid. Under any circumstances, the ceramic filter plate does not allow air to pass through. Because there is no air to pass through, the energy consumption during solid-liquid separation is low and the vacuum degree is high.
